Image of the tympan or plate - click for larger version
Tympan 5b
This plate contains a table of horizons.

Scales


Type Range & Units Numbered Geometry Location
Declination 0 - 24 Degrees Every 6 degrees Linear n/a
Table of Horizons 22 - 66 Degrees of latitude Every 2 degrees n/a n/a
